Aluminum Sheet

» Aluminum Sheet

    • Color coated aluminum sheet

    CATEGORY AND TAGS:
    Aluminum Sheet ,

    Thickness: from 0.06mm to 1.0mm

    Width: from 1200mm to 2800mm

    Temper: O-H112

    enquiry
    • Specifications
    Alloy A1100,A1050,A3003,A3005,A3104,A3105,A5052,A5182,A8011,etc.
    Temper H16,H18,H19,H24,H26,H48
    Thickness From 0.06mm to 1.0mm
    Width Standard width:1240mm
      Special width:1300mm,1400,1520mm,1570mm (largest 2800mm)
    Diameter Standard dia:1200mm
      Interior dia:75mm,150mm,405mm,505mm
    Weight 2.5 T/coil,3.0 T/coil
    Coating PE,PVDF,ACRYLIC,EPOXY,DOS
    Surface Mill Finished, Coated, Embossed, Brushed
    Color RAL code
    Gloss 10-90%(EN ISO-2813:1994)
    Coating Thickness PE: more than 18 micron
      PVDF: more than 25 micron
    Coating Hardness

    (pencil resistance)

    		 More than 2h
    Coating adhesion 5J(EN ISO-2409:1994)
    Impact Resistance No peeling or cracking(50 kg/cm,ASTMD-2794:1993)
    Flexibility(T-bend) 2T
    MEK resistance More than 100
    Advantage 1.High temperature resistant 2.Weathering resistant 3.Scrubbing resistant
    4.Sound insulation 5.Acid or alkali proof

    6. Fireproof    7.Light weight material is easy to construct and install
    Out package Wooden splint with export standard
    Application Cans cover ring, ACP, wall cladding, facades, roofs and canopies, ceilings, signboards, blind window, display platforms, electrical panels, etc
