Thickness: from 0.06mm to 1.0mm
Width: from 1200mm to 2800mm
Temper: O-H112
enquiryAlloy | A1100,A1050,A3003,A3005,A3104,A3105,A5052,A5182,A8011,etc. |
Temper | H16,H18,H19,H24,H26,H48 |
Thickness | From 0.06mm to 1.0mm |
Width | Standard width:1240mm |
Special width:1300mm,1400,1520mm,1570mm (largest 2800mm) | |
Diameter | Standard dia:1200mm |
Interior dia:75mm,150mm,405mm,505mm | |
Weight | 2.5 T/coil,3.0 T/coil |
Coating | PE,PVDF,ACRYLIC,EPOXY,DOS |
Surface | Mill Finished, Coated, Embossed, Brushed |
Color | RAL code |
Gloss | 10-90%(EN ISO-2813:1994) |
Coating Thickness | PE: more than 18 micron |
PVDF: more than 25 micron | |
Coating Hardness
(pencil resistance) |
More than 2h |
Coating adhesion | 5J(EN ISO-2409:1994) |
Impact Resistance | No peeling or cracking(50 kg/cm,ASTMD-2794:1993) |
Flexibility(T-bend) | 2T |
MEK resistance | More than 100 |
Advantage | 1.High temperature resistant 2.Weathering resistant 3.Scrubbing resistant 4.Sound insulation 5.Acid or alkali proof 6. Fireproof 7.Light weight material is easy to construct and install |
Out package | Wooden splint with export standard |
Application | Cans cover ring, ACP, wall cladding, facades, roofs and canopies, ceilings, signboards, blind window, display platforms, electrical panels, etc |
